SoilWise GeoPackage

Introduction to the SoilWise GeoPackage (SQLite)

The Soilwise GeoPackage is the relational (SQLite‑based) container adopted by the SoilWise project (Horizon Europe – Mission Soil) to enable exchange, storage, and GIS‑native use of soil data, with the explicit goal of making them FAIR and reusable across European policies, research, and land‑management workflows.¹² SoilWise provides an integrated, actionable entry point to scattered soil data and knowledge, recognising existing workflows and repositories and connecting to them through a modular, scalable architecture designed to last beyond the project horizon and co‑created with stakeholders.¹²

Why GeoPackage/SQLite

GeoPackage is an OGC open, portable, self‑contained standard for geospatial data. Being an SQLite container, it allows direct use of vector features, rasters/tiles and attribute data in a single file, without intermediate format translations. This makes it ideal for GIS environments and for constrained connectivity scenarios.³⁴
Within the INSPIRE ecosystem, an endorsed Good Practice describes how to design and publish INSPIRE datasets encoded as GeoPackage, while preserving legal and technical compliance with the Implementing Rules (with technical conformity demonstrable through transformation to the default encoding, GML). The Good Practice promotes logical models optimised for GIS usability, with explicit mapping rules from the INSPIRE conceptual model.⁵⁶

Continuity with INSPIRE: from EJP SOIL to Soilwise

The Soilwise database builds upon—and updates—the work carried out around INSPIRE, including the EJP SOIL GeoPackage template for the Soil (SO) theme. That template focused on semantic harmonisation, code‑list management, and repeatable transformations, and is a relevant baseline for Soilwise’s relational modelling approach.⁷ This direction aligns with community guidance on publishing INSPIRE data as a relational database (GeoPackage as a specialisation of SQLite), including recipes and patterns for harmonisation and publication.⁸

Data architecture and governance

In line with the INSPIRE Good Practice, each GeoPackage logical schema should be accompanied by:

• a model description (including benefits and limitations compared to the default encoding);
• an empty GeoPackage template for distribution;
• an executable specification for model transformation (UML→GPKG or GML→GPKG), aligned with the generic INSPIRE transformation rules.⁵

This approach ensures traceable compliance, supports reuse across thematic communities, and allows use‑case‑specific logical models while preserving a coherent methodological and semantic framework.⁵

Integration with OGC SensorThings API 2.0 (STA2)

Within SoilWise, an implementation of OGC SensorThings API 2.0 (STA2) is used to expose observations and metadata as interoperable time series via HTTP and MQTT, consistent with O&M / ISO 19156:2023. The STA2 draft (OGC document 23‑019) updates the data model and bindings (e.g., OData 4.01 alignment), strengthening the API’s role as a standards‑based “data‑in‑motion” complement to the GeoPackage’s “data‑at‑rest” layer.⁹¹⁰
The growing adoption of SensorThings for observational data (well beyond narrow IoT use) is documented by OGC/WMO community materials, which highlight alignment with the renewed OMS/ISO 19156:2023 standard and integration with GIS tools.¹¹¹²

QGIS usage and custom forms

The Soilwise GeoPackage is natively supported by QGIS, enabling editing, styling, and map production with no format conversion. To improve data‑entry quality and speed, we recommend configuring custom attribute forms (widgets, value map/relation, constraints and expressions) and adopting a design of tabs and groups aligned with project code lists and validation processes.¹³¹⁴

Relational Structure of the GeoPackage (INSPIRE UML + STA2 Transposition)

Purpose and framing

This GeoPackage implements a relational schema that is a faithful transposition of the INSPIRE Soil conceptual model (UML) and its classes/associations, as described in the INSPIRE Soil Technical Guidelines and Feature Catalogue. It also integrates the OGC SensorThings API 2.0 (STA2) model for the management and exposure of observations (time‑series and observation metadata).⁵⁹¹⁰

Sources of the model (normative and technical)

• INSPIRE Soil – Technical Guidelines: define the content, the Feature Catalogue and the UML elements of the Soil theme, plus implementation recommendations.⁵¹⁵
• INSPIRE Good Practice – GeoPackage encoding: describes how to publish INSPIRE datasets using the OGC GeoPackage standard, while preserving legal and technical compliance; it promotes GIS‑oriented logical models and executable mappings from the conceptual model.⁵⁶¹⁵
• OGC SensorThings API 2.0 (STA2): provides the data model and API for Things, Datastreams, Observations, Sensors, ObservedProperties, including HTTP/MQTT bindings and alignment with O&M / ISO 19156:2023.⁹¹⁰

From UML to a relational GeoPackage (SQLite)

The translation into GeoPackage follows widely adopted relational design rules, consistent with INSPIRE/OGC guidance:

1. UML Classes → Tables
   Each INSPIRE Feature Type (e.g., SoilSite, SoilPlot, SoilProfile, ProfileElement) becomes a table; attributes map to typed columns; spatial attributes are stored in geometry columns as per GeoPackage.³⁴⁵¹⁵

2. UML Associations → Foreign Keys
   UML cardinalities are enforced through foreign keys and (where required) link tables for 1:N / N:M relationships, preserving the Soil chain Site → Plot → Profile → ProfileElement defined at the conceptual level.⁵¹⁵

3. Code lists → Reference tables
   Controlled vocabularies (INSPIRE and other allowed authorities) are materialized as code‑list tables, typically keeping URI / notation / label / authority / version to ensure semantic interoperability.⁵¹⁵

4. Observational component (STA2)
   STA2 entities Thing / Datastream / Observation / Sensor / ObservedProperty are mapped to dedicated tables. Observation rows reference their Datastream, keep temporal attributes (phenomenonTime, resultTime), and a result (numeric or textual) according to STA2. This design makes the observational layer complementary to the core INSPIRE Soil features, and ready for standards‑based exposure via the STA2 API.⁹¹⁰

Key INSPIRE Soil features (concise overview)

• SoilSite — Context/area of investigation: an area (often polygonal) providing the context within which one or more specific investigations are carried out; it acts as a logical container to combine or compare investigations performed at nearby points/times.⁵

• SoilPlot — Investigation point/portion: a point or area where a specific investigation is performed (e.g., pit, borehole, sample location); it is contained in a SoilSite and is the operational focus of many descriptions and measurements.⁵

• SoilProfile — Vertical cross‑section: the section from ground surface down to material not modified by pedogenesis; it is the basis for describing horizons or layers (modelled as ProfileElement).⁵

• ProfileElement — Horizon or layer: either a SoilHorizon (a pedogenetic horizon homogeneous by physical/chemical/biological properties) or a SoilLayer (a depth‑defined layer, not necessarily equal to a horizon).⁵

• SoilBody — Mapping unit: an association of co‑occurring soils in an area (conceptually similar to a Soil Mapping Unit), typically linked to one or more representative SoilProfile(s).⁵

Data Loading & Modelling Guide

Data Loading & Modelling Guide document is the practical guide for populating (loading) the GeoPackage.
It explains, clearly and in sequence:

• the order in which datasets must be loaded and their dependencies;
• the constraints to respect (e.g., required fields, minimum cross-table consistency);
• what to verify before/after loading to ensure a correct result.

QGIS Manual

A practical guide to using QGIS to read from and write to the database (GeoPackage), supported by custom Forms that simplify data entry and updates.

Custom Forms

The Forms are designed to guide users in filling fields correctly:

• Guided fields with drop-down menus, default values, and contextual help.
• Validation checks to flag incomplete forms or inconsistent values.
• Sections that group the most used fields and hide technical fields.
• Actions (where available) for automatic completion or quick checks.

Database Tables

This chapter provides the detailed description of all database tables.
For each table, you will find its purpose, key fields, any geometry, the most relevant relationships, and usage notes.

• codelist
• datastream
• derivedprofilepresenceinsoilbody
• faohorizonnotationtype
• isbasedonobservedsoilprofile
• isbasedonsoilbody
• isbasedonsoilderivedobject
• isderivedfrom
• observation
• observedproperty
• observingprocedure
• obsprocedure_obsdproperty
• obsprocedure_sensor
• otherhorizon_profileelement
• otherhorizonnotationtype
• othersoilnametype
• profileelement
• sensor
• soilbody
• soilbody_geom
• soilderivedobject
• soilplot
• soilprofile
• soilsite
• thing
• unitofmeasure
• view observation
• wrbqualifiergroup_profile
• wrbqualifiergrouptype

Relationship Summary

This document helps you understand how tables are connected.
It highlights the most relevant links and suggests when tables should be used together—useful to navigate between core entities and supporting tables.

Cascade Summary

This document explains how the system manages the consequences of updates and deletions across related tables.
It clarifies what happens to related records and how to keep data consistent when modifying “parent” or “child” data.
